NW-B-P10
E318168ce
- – This system could play various media files smoothly with supports of multiple animation and video format hard decoding
- – Various expressions and vivid contents with powerful visual impact
- – To get better picture quality than display screen with less cost
- – Low-power consumption with timing control: Energy saving with less light pollution
- – Significant increase lifespan of LED through low voltage and low current with ultra-low temperature operation
- – The distance of light source is 2.5-3CM away from the canvas which is suitable for light boxes with a thickness of 6CM or more
- – Highly modular, easy to install and maintain
Description
| Part No. | Input Voltage | Max Power(W/piece) | Product Size(mm) | Lumen/piece | LED Type | Max Current(A/piece) | Max Run(pcs) |
|---|
| NW260-B-P10-A1 | 5VDC | 26W | 320*320 | 2000 lm | 2835 | 5.2 | 2pcs |
| NW260-B-P12-A2 | 5VDC | 26W | 384*384 | 2000 lm | 2835 | 5.2 | 2pcs |
| NW128-B-P20-A1 | 5VDC | 12.8W | 320*320 | 1000 lm | 2835 | 2.56 | 3pcs |
| NW064-B-P20-A2 | 5VDC | 6.4W | 320*160 | 500 lm | 2835 | 1.28 | 6pcs |
| NW064-B-P20-A1 | 5VDC | 6.4W | 160*320 | 500 lm | 2835 | 1.28 | 6pcs |
| NW032-B-P20-A1 | 5VDC | 3.2W | 160*160 | 250 lm | 2835 | 0.64 | 12pcs |
